Quick Details

  • Type: Other, Packing Machine
  • Condition: New
  • Application: Machinery & Hardware
  • Packaging Type: Cartons
  • Packaging Material: Paper
  • Automatic Grade: Automatic
  • Driven Type: Electric
  • Voltage: 380v or according to your requirements
  • Power: 6-10kw
  • Place of Origin: Hebei, China (Mainland)
  • Brand Name: automatic folding carton box gluing machine
  • Model Number: automatic folding carton box gluing machine
  • Weight: according to the machine size
  • Dimension(L*W*H): according to the machine size
  • Certification: ce
  • After-sales Service Provided: Overseas service center available

Packaging & Delivery

Packaging Details common type and container
Delivery Time 30 days after receiving the deposit



BL series automatic Carton folder Gluing machine/carton box gluer machine





Detailed Product Description





BL series automatic gluing machine  consist of three part which is feeding paper part, glue folding part and counting piling part, adjust the speed by digital, micro-adjust the phase by computer, with simple quick reliable and precise controlling style, automatic feeding paper, automatic gluing and folding, automatic counting ,automatic stacking and outputting, average gluing speed is 150pcs/min,max speed is 220pcs/min.High efficiency, save energy, environmental is our top pursuit.



Function and characteristic



Automatically finish the top folding and middle folding, meanwhile finish the glue belt glue of the upper and down part, save labor and time



  suitable range is wide,can be used in different size of carton,convenient to adjust



The machine work steadily and reliable,the effect is firm and good looking



Easy to operate and easy to maintainance



Automatic amend the carton right-angle degree



Main  structure  of   machine



Feeding   Section



1.Vacuum   suction   feeding   to   feed  warping   paperboard   easily



2.Quality  electromagnetic   clutch  and  brake  adpoted,  feeding  section  controled  independent,operation  easily



3.Scorer  wheel  adjustable, suit  for 2-8mm  thick  paperboard



4.Second  creasing  struction  can  press  again  the  paperboard  which was  not  creased  well



 Guling  and  Folding  Section



1.Simple  structure  and  high  reliability, glue  quantity  adjustable, cleaning  easily



2.Stainless  steel  glue  wheel  adopted,long  life  snd  saving  glue  cost



3.Imported  quality  rubber  belt  adopted,automatic  folding



4.With  paperboard  rectify  device  snd  creasing  rectify  device



Counter  and Stacker  Section



1.Stacking  and  counting  are  simple  and  reliable



2.Digital  control,operation  easily  and  reliable. No-stop  put  in  data  and  automatic  counting



3.With  rectification  function



4.Paperboard  counting  and  put  out  by  pneumatic,  stable  and  quickly




Main technology parameter



Model

Yl-2000

YL-2400

YL-2800

max Cardboard

1000*2000mm

1200*2400mm

1400*2800mm

Min Cardboard

260*600mm

300*800mm

300*800mm

Installation area

2400*13500mm

2800*15500mm

3000*15500

Power Required

6.5kw

8.0kw

10.5kw







Remark:can make the machine by the user's requirement
