corrugated paperboard 4 colors printing and slotting with slotting attachment
Printing department :
1. The machine USES 360 degrees planetary motor phase adjustment
(microcomputer digital phase meter) can directly input digital, adjust faster, higher accuracy.
2. Separate and combine by electric, preumatic lock, pneumatic brake device,
ensure precise position ,electric counter, the operation is convenient and quick.
3. Distributing device, ink forme roller with automatic idle function, make when machine stop
ink won't dry.
4. Drive gear, gear for 40Cr, helical gear by grinding, high frequency quenching technology
(accuracy level is above 6 ) finishing and become, part of the position is adopt keyless connection .
5. Lubrication device: this machine adopt the automatic (mechanical pump) spray type circulation
lubrication device, automatic spray oil, inking amount evenly, each group and circulation,
and improve the service life of the gear and the precision of the chromatically.
7.Electrical appliances: the main parts imported schneider, Siemens, and other well-known manufacturers, its stability greatly increased.
8.Anilox roll number can provide 180-260 mesh (optional).
Slotting and die cutting department :
1)Slot part with synchronous transfer to four linkage, thereby greatly improving the production efficiency.slotting
department and die cutting department are in one unit ,can save cost for you ,when you produce
normal box ,you can use the slotting device ,and when you produce abnormal box ,you can use the
die cutting department ,it is very convenient ,and very economic .
2)the slotting knives are from Qingdao production, using high-quality front steel material, the forging, high frequency quenching processes, finishing and become, internal tooth
shape design (month teeth) knife sharp, durable.
3)Electrical appliances: the main parts imported schneider, Siemens, and other well-known manufacturers, its stability greatly increased.
4).Die-cutting roller adopt high quality casting material, thickness is 30 mm, with good quality and dynamic balancing correction,
hard chromium plating.
5).Main body wallboard adopt high quality cast iron material, wall thickness is 50 mm,processing by large-scale machining center.
6).Soft roller automatically repair institutions improve gluesheath of repeated use, can repair 3-4 times.
7).Linear speed automatic compens19000ation, to ensure that each batch of carton die-cutting size exactly.
8).Imported Taiwan MaxDura BRAND RUBBER, convenient installation, the die cutting times can up to 120 million times.
9).Six levels of fine grinding gear using 40 cr material, low noise, long service life.
10).Die-cutting roller cylinder type auto separation unit, decrease adhesive wear of gluesheath (controlled by photoelectric).
11).Lubrication system, adopting the mechanical pump oil supply device, automatic spray the circulating oil,lubricate evenly,
improve the service life of gear.
Note :the slotting department and the die cutting department are in one unit ,when you make abnormal boxes ,
you can install the wooden die on it to make abnormal boxes,when you make normal boxes ,
you can use the slotting knives only ,not install the wooden dies .it is more economic for the client,
